Silverline 633630 - Product Familiarisation and Intended Use; Product Components; Intended Use; Operation and Maintenance

EN
8
1 Grinder
2 Collet
3
Collet Spanners
4 Quick Connector
5 Inline Oiler
6 Air Hose
7
Grinding Stones
8 Machine Oil Bottle
Product Familiarisation
Intended Use
Airmicrogrinderkitpoweredbyanaircompressor,usedforprecisiongrinding,sanding,honing,
polishingormachiningmaterial(metal,plastic,woodetc).Utilisesmountedgrindingstones,rotary
rasps, surface conditioning pads and other sanding and grinding tools.
Not intended for commercial use.
The tool must ONLY be used for its intended purpose. Any use other than those mentioned in this
manualwillbeconsideredacaseofmisuse.Theoperator,andnotthemanufacturer,shallbeliable
for any damage or injury resulting from such cases of misuse. The manufacturer shall not be liable
foranymodicationsmadetothetool,norforanydamageresultingfromsuchmodications.
Unpacking Your Tool
• Carefullyunpackandinspectyourtool.Fullyfamiliariseyourselfwithallfeaturesand
functions of it
• Ensure all parts of the tool are present and in good condition. If any parts are missing or
damaged, have such parts replaced before attempting to use this tool
Before Use
WARNING: Alwaysdisconnectthetoolfromtheairsupplybeforeadjustmentormaintenance
is carried out.
Recommended air supply
• Thistoolshouldbeconnectedtoaclean,dryairsupplywithinlineoilerandwaterseparator
• Donotallowsupplypressuretoexceedthemaximumstated(see'Specication')
• Ensurethatwaterisdrainedfromairsystemdaily
• Ensure that all parts of the system (hoses, couplers, etc.) are correctly rated for the air pressure
to be used
Connecting the inline oiler & quick connector
Note:Thistoolissuppliedwithtwodifferentmaleairlinequickconnectors(Fig.II):
EQ-4 – commonly used in Europe
EN-6 – mainly used in the UK
Iftheairsupplydoesnothaveaninlineoiler,connectthesuppliedInlineOiler(5)betweenthe
AirHose(6)andQuickConnector(4):
1. ApplysomePTFEtape(notincluded)tothescrewthreadsoftheQuickConnectorandInlineOiler.
Thiswillhelptomaintainanairtightseal
Note: ApplyPTFEtapetightlyandinaclockwisedirection,soitdoesnotcomeoffwhenthethread
isscrewedintothetool.
2. Connect the air inlet of the Air Hose to the female threaded connection on the Inline Oiler, and
the Quick Connector to the male threaded end of the Inline Oiler
3. OntheInlineOiler,unscrewthescrewxingtoaccesstheoilreservoir.Fillthereservoirwith
air tool oil
IMPORTANT: DO NOT UNDER ANY CIRCUMSTANCES USE NORMAL ENGINE OIL.
4. Retscrewtore-sealthereservoir
• If the Inline Oiler is not required, connect the Quick Connector directly to the Air Hose air inlet.
WARNING:Donotattachthetooltoahoseandthehosetoacompressorwithonlythreaded
connections.Alwaysusequickconnectorssothetoolcanberemovedfromtheairsupply
connectionwhenneededforsafeoperation.
WARNING:Nevertafemalequickconnectordirectlytotheleaderhose/whiphoseordirectly
tothetool.Thestoredpressurisedairinthetool,evenwhendetachedfromthemainairsupply,
can operate the tool unexpectedly.
Fitting an accessory
WARNING:Alwaysdisconnectthetoolfromtheairsupplybeforeinstalling/removing
accessories.
1. InserttheshankoftheaccessoryasfarintotheCollet(2)asitwillgo
2. TightentheColletbyhand,thentthetwosuppliedColletSpanners(3):oneontheCollet,the
other on the drive shaft (Image A)
3. TightentheColletsothattheaccessoryissecurelyxedinplace.Pullontheendoftheaccessory
to check
4. Toremovethegrindingstone:loosentheColletusingtheColletSpannersandwithdrawthe
accessory
Operation
1. Connect tool to air supply and turn ON air supply
2. Holdthebodyofthemachinewithonehand,ensuringthegrinderheadisnotincontactwith
any object (Image B)
3. Withtheotherhand,rotatebarrelswitchatthebaseoftheGrinder(1)clockwisetotheON
position to start the grinder
Note: Thebarrelswitchcanbeusedtoregulatetheairowandthereforethespeedofthetool,
dependingonthepositionoftheswitchbetweentheOFFandONposition
4. Rotatebarrelswitchcounter-clockwisetotheOFFpositiontoturnOFFthegrinder
IMPORTANT:Neverrunthegrinderwithoutoilintheinlineoiler.
Accessories
• Accessories for this tool are available from your Silverline stockist
• Spare parts can be obtained from your Silverline dealer or toolsparesonline.com
Maintenance
WARNING:Alwaysdisconnectfromtheairsupplyanddepressurisebeforecleaningorcarrying
out any maintenance.
General inspection
• Regularlycheckthatallthexingscrewsaretight.Theymayvibratelooseovertime.
Cleaning
• Keepyourtoolcleanatalltimes.Dirtanddustwillcauseinternalpartstowearquickly,and
shortenthetool’sservicelife.Cleanthebodyofthetoolwithasoftbrushordrycloth
IMPORTANT:Thereisverylittlethatcangowrongwithyourairtool,anditshouldbenotedthat
whenanairtoolfailstoworkitisgenerallybecausetheinternalworkingshavecorrodeddueto
dirty,wetairandfailuretofollowtheinstructionsgivenbelow.
Daily maintenance procedure:
Ifaninlinelubricatorisnottted,thefollowingmaintenanceproceduremustbeperformeddaily:
1. Disconnect from the air supply
2. Pour 3-4 drops of oil into the air intake
3. Operatethemachineatlowspeedtothoroughlylubricateallinternalworkings
• If the machine is in constant use or used for long periods at a time, repeat the above procedure
up to 3 times per day
• Use air tool oil. DO NOT UNDER ANY CIRCUMSTANCES USE NORMAL ENGINE OIL
• Failuretocomplywiththeoperatingandmaintenanceinstructionsmayinvalidatetheguarantee
Storage
• Store this tool carefully in a secure, dry place out of the reach of children
