aRC MoUnting
In order to install the stainless stel arc, perform the next operations
(Fig.8):
- hinge out the seat of stern locker;
- insert arc stud in the stern surface holes ;
- x arc by means of the nuts M12 and bolts M12, M8,
serrated lock washersand washers from the complete set ;
- tighten all nuts and bolts;
- replace the locker seat.
In order to install the stainless stel arc, perform the next operations
(Fig.8a):
- hinge out the seat of stern locker;
- insert arc stud in the stern surface holes ;
- x arc by means of the nuts M12, serrated
lock washersand washers from the complete set ;
- tighten all nuts n order to install the stainless stel
arc, perform the next operations (Fig.8):
Рис.8
Рис.8а
