inflation / deflation ValVeS oPeRation
The ination/deation valve is intended for:
— lling the compartment with air from a standart
pump or lling system and maintaining pressure in the
tube for prolonged time.
— adjustable drop of pressure in compartment.
The air ll valve is designed as a tab-type non-return valve.
Every ination / deation valve includes the following parts : valve body 1,
valve nut 5, valve cap 2 with strap 3, washerwith gasket 4, spindel 6 with
spring 7, cup diaphragm 8 ( Fig.1).
INFLATION MODE : valve is closed with gasket 4 tight . To move the valve
to deation mode : push the button 6 and turn it clockwise to x it in lower
position
DEFLATION MODE : button is xed in lower position. To move the valve to
ination mode : push the button 6 and turn it counter clockwise. The button
goes to upper position.
Fig.1
4
7
8
6
5
3
2
1
ATTENTION !
1. Overinating of your boat, when the air pressure is
more than nominal, sufciently decreases the boat life time.
2. The valves are airtight just in case they are closed with the caps
tight.
3. The tube is airtight in case it keeps its form for 8 hours at least.
