DO NOT use lift table if any malfunction or fault is found.
(1) Check for scratch, bending or cracking on the lift table.
(2) Check if there is any oil leakage from the cylinder.
(3) Check the vertical creep of the table.
(4) Check the smooth movement of the wheel.
(5) Check the function of brake.
(6) Check if all the bolt and nuts are tightened firmly.
4. OPERATING LIFTTABLE
4-1. How to use the brake.
Brake lift table when not moving it in order to prevent sudden movement.
The brake is equipped with the swivel caster on the right side.
(1) Braking the wheel, press the brake pedal.
(2) Releasing the brake, lift up the brake pedal.
4-2 Lifting the table
1. DO NOT overload lift table, stay within its rated capacity.
2. DO NOT side end load must be distributed on at least 80% of table area.
Press the lifting pedal several times the until the table reaches the desired position.
The table does not elevate after reaching the highest position even if the lifting pedal is pressed.
The table lowers slightly after reaching the highest position.
MAXIMUM CAPACITY OF TABLE
