LIQUID COOLER RADIATOR SUPPORT
The front fan slots support 120mm or 240mm radiators.
The total length limitation for radiator in this area is 310mm.
Graphics card length support will vary depending on the
thickness of the radiator used.
2
The rear fan slot supports one 120mm radiator.
The 41mm of clearance from the right edge of fan slot is
to the motherboard surface.
If you wish to install a radiator in this position, please
ensure motherboard components do not interfere with it.
1
41mm
310mm
Micro ATX M
Mini ITX I
