Product Overview
Rear Panel
Mobile Series MS08
Front Panel
2
Drive access indicator Drive front panel Door lock switch
15 Pin SATA power 7 Pin SATA data RAID mode Confirm button
connector connector Switch for RAID mode change
Confirm button: After selecting RAID mode, please press “Confirm button” for 5
seconds.
Note: Mode setting change will only take effect when powered so please perform this
action with the 15pin SATA power connector connected before installing it into the
computer chassis!
