General Usage Instructions
Opening the Tent
1. Remove the water proof cover from the tent by
undoing the 2 Velcro straps and unzipping the
cover. Take off of tent and then let fall to the
side.
2. Tucked between the mattress and tent base is
the packet of awning rods. Remove this packet
and place to the side for a later step.
3. There are 4 Velcro straps, one on each corner of
the tent, that hold it down. Release all of these
straps (see Fig. 3).
4. Slide the ladder out until the locking pins en-
gage, and then pull on the ladder to help open
the tent all the way (see Fig. 4). Set ladder on the
ground. Make sure ladder lock pins are secure
and will not slip.
5. It is recommended that the ladder is at an angle
when being used. If it looks too vertical, adjust
the extension until at an appropriate angle.
6. There are 8 rods, 4 for the side window awnings
and 4 for the rainfly. On the outside of the tent
are 4 flaps, 2 on each side, (see Fig. 5) that cover
pre-drilled holes on the base.
7. Place the base of each rod through the flaps and
into the pre-drilled holes, then attach the hook in
the grommet in the corner of the rain fly (see Fig.
6), with the hook facing outward.
8. The rods should bow out at an angle (see Fig. 7)
to keep tension. Finish installing the rods on each
corner of the rain fly and of each window.
Always make sure your ladder is securely fas-
tened and to the tent and securely positioned be-
fore entering or exiting the tent.
Figure 3
Figure 4
Figure 5 Figure 6
Figure 7
