3
| 3 11
Corner
Bracket
4X
M8 X 16
(re-used)
4X
Slot-Nut M8
(re-used)
4X
500MM
(re-used)
1X
Parts re-used (R) from your existing
GT1-EVO build.
The corner brackets are from the Front
Mount hardware kit since they need to
retain their aligning tabs.
Brackets from your existing GT1-EVO build
with their tabs broken off, can be re-used
as well. We’ll show this on Page 6.
A4
R
R
R
To Next Page
