14
| 14 17
HEEL REST (optional purchase)
C1 Heel rest 1
C2 Bolt M6 X 40 DIN 7991 4 Countersunk
C3 Bolt M6 X 35 DIN 7991 4 Countersunk
C4 Plastic sleeve M8 X 20 4
C5 Plastic sleeve M8 X 10 4
C6 Slot-Nut M6 4
C7 Lock-Nut M6 4
Disclaimer: for some entries on this list, we supply more than required as spare
materials. Don’t worry if you have some leftovers, this is intentional.
PEDAL BASE PLATE
# Part QTY Note
A1 Pedal base plate 1
A2 Bolt M8 X 16 DIN 912 4
A3 Bolt M8 X 12 DIN 912 4
A4 Bolt M6 X 20 DIN 912 12
A5 Bolt M5 X 25 DIN 912 12
A6 Bolt M8 X 20 DIN 7991 4 Countersunk
A7 Washer M8 DIN 125-A 8
A8 Spacer male/female M8 X 15 4
A9 Slot-Nut M8 6
A10 Lock-Nut M8 6
A11 Lock-Nut M6 12
A12 Lock-Nut M5 12
SEAT SLIDER (optional purchase)
# Part QTY Note
B1 Seat slider LEFT 1
B2 Seat slider RIGHT 1
B3 Seat slider handle 1
