OPTICS
Optical system: optical engine based on 1 DMD™ chip; sea
led dust-proof housing
DMD™ panel: TI HD2+ 0,8” 12° Dark Metal - 1280x720
pixel (16:9 aspect ratio)
Projection Lens: UltraWide angle F/2.4
Color Wheel: 6 segments RGBRGB) - 9000 rpm max
Lamp: 120 W - 6000 hours *
Picture size: 1218 x 685 mm (48 x 27 in)
Contrast: >1800:1
* (average value measured in the laboratory under optimal conditions; can
be reduced by improper use)
GENERAL
Power supply cable: (EU, UK e US); length 2m
Power supply: from 100 to 240 Vac, +/- 10% tolerance,
48 to 62 Hz frequency
Consumption: 170 W max
Fuse: T 3.15A H. 5 x 20 mm
Dimensions: 1495 x 1218 x 421 mm (LxAxP)
Weight (approx.): 85 kg
Operating temperature: 10 a 35°C
Transportation temperature: -15 a 55°C
Storage temperature: -15 a 55°C
Humidity: 20% to 95% non-condensing
Safety: EN 60065
Electromagnetic comp.: EN 55013
EN 55020
EN 61000-3-2
EN 61000-3-3
Trasportation: IEC 68-2-31, IEC 68-2-32
ELECTRICAL
Input signals:
• 1 COMPOSITE VIDEO (CVBS)
RCA type connectors
1,0 V
pp
/ 75 Ω, negative sync
A TECHNICAL SPECIFICATIONS
• 1 S-VIDEO (Y/C)
4 pin mini-DIN connectors
Y: 1,0 V
pp
/ 75 Ω, negative sync
C: 0,286 V
pp
/ 75 Ω [NTSC nominal burst level]
0,3 V
pp
/ 75 Ω [PAL, SECAM nominal burst level]
• 2 COMPONENTS (Y/Cr/Cb/H/V) - RGBHV
2 sets of 5 RCA type connectors
- Components signal
Y: 1,0 V
pp
/ 75 Ω, negative
or 3 level
sync
[HDTV]
Cr,Cb:
0,7 V
pp
/ 75 Ω
- RGB signal
R,B: 0,7 V
pp
/ 75 Ω
G: 0,7 V
pp
/ 75 Ω, H, V o HV separate sync
1,0 V
pp
/ 75 Ω, negative
or 3 level
sync
[HDTV]
H,V: positive or negative TTL , 0,3-5 V
pp
/ 1 kΩ
• 1 RGBHV (analogue RGB)
female DB15HD connectors
R,B: 0,7 V
pp
/ 75 Ω
G: 0,7 V
pp
/ 75 Ω, H, V o HV separate sync
1,0 V
pp
/ 75 Ω, negative
or 3 level
sync
[HDTV]
H,V: TTL positive or negative TTL, 0.3-5 V
pp
/ 1 kΩ
• 1 DVI (digital RGB/YCrCb)
female DVI-D connector
• 1 HDMI™
• 1 Optical Audio Output
TOSLINK connector
Control: Keypad (front panel), IR remote control,
RS232 from PCs or home automation devices
Horizontal frequency: from 15 to 80 kHz (up to UXGA, 60 Hz)
Vertical frequency: 48 -100 Hz
Video Standards: PAL (B, G, H, I, M, N, 60), SECAM, NTSC
(3.58 e 4.43), automatically selected
High definition video: ATSC HDTV (480p, 720p, 1080i, 1080p)
Graphic Standards: VGA, SVGA, XGA, SXGA, UXGA
Deinterlacing: Faroudja chip set, DCDi™ , 3:2 pull down
sequence convertion
Colour Temperature: from 6000 to 10000 °K (3 presets, 1 user
adjustable)
