Air/water inverter chillers and heat pumps with axial fans
 Format Bit R/W  Name  Note
952 BIT MASK
0
R - Alarms ⁴ ⁵
Probe 1 error E611
1 Probe 2 error E621
2 Probe 3 error E631
3 Probe 4 error E641
4 Probe 5 error E651
5 Probe 6 error E661
6 Probe 7 error E671
7 Probe 8 error E681
8 Probe 9 error E691
9 Probe 10 error E701
10 Probe 11 error E711
11 Module 1 probe 1 error E612
12 Module 1 probe 2 error E622
13 Module 1 probe 3 error E632
14 Module 1 probe 4 error E642
15 Module 1 probe 5 error E652
953 BIT MASK
0
R - Alarms ⁴ ⁵
Module 1 probe 6 error E662
1 Module 1 probe 7 error E672
2 Module 1 probe 8 error E682
3 Module 1 probe 9 error E692
4 Module 1 probe 10 error E702
5 Module 1 probe 11 error E712
6 Module 2 probe 1 error E613
7 Module 2 probe 2 error E623
8 Module 2 probe 3 error E633
9 Module 2 probe 4 error E643
10 Module 2 probe 5 error E653
11 Module 2 probe 6 error E663
12 Module 2 probe 7 error E673
13 Module 2 probe 8 error E683
14 Module 2 probe 9 error E693
15 Module 2 probe 10 error E703
954 BIT MASK
0
R - Alarms ⁴ ⁵
Module 2 probe 11 error E713
1 Link inverter 1 E801
2 Link inverter 2 E802
3 Link inverter 3 E803
4 Hardware fault inverter 1 E851
5 Hardware fault inverter 2 E852
6 Hardware fault inverter 3 E853
7 Overcurrent inverter 1 E861
8 Overcurrent inverter 2 E862
9 Overcurrent inverter 3 E863
10 High temperature inverter 1 E871
11 High temperature inverter 2 E872
12 High temperature inverter 3 E873
13 Bad voltage inverter 1 E881
14 Bad voltage inverter 2 E882
15 Bad voltage inverter 3 E883
