Sime 8099060 - Table of Contents; Burner Description; Burner Equipment; BURNER EQUIPMENT Flange with Insulating Gasket

2685
1
GB
4
INDEX
1. BURNER DESCRIPTION
One stage light oil burner.
1.1 BURNER EQUIPMENT
Flange with insulating gasket . . . No. 1 Screw and nuts for flange to be fixed to boiler . . No. 4
Screw and nuts for flange . . . . . . No. 1 Flexible oil pipes with nipples . . . . . . . . . . . . . . No. 2
Grommet . . . . . . . . . . . . . . . . . . . No. 1 7 pin plug. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . No. 1
Hinge. . . . . . . . . . . . . . . . . . . . . . No. 1
1. BURNER DESCRIPTION . . . . . . . . . . . . . 1
1.1 Burner equipment . . . . . . . . . . . . . . . . . . 1
2. TECHNICAL DATA . . . . . . . . . . . . . . . . . 2
2.1 Technical data . . . . . . . . . . . . . . . . . . . . . 2
2.2 Overall dimensions. . . . . . . . . . . . . . . . . . 2
2.3 Working field . . . . . . . . . . . . . . . . . . . . . . 2
3. INSTALLATION . . . . . . . . . . . . . . . . . . . . 3
3.1 Boiler fixing . . . . . . . . . . . . . . . . . . . . . . . 3
3.2 Hydraulic systems . . . . . . . . . . . . . . . . . . 4
3.3 Electrical wiring . . . . . . . . . . . . . . . . . . . . 5
4. WORKING . . . . . . . . . . . . . . . . . . . . . . . . 6
4.1 Combustion adjustment . . . . . . . . . . . . . . 6
4.2 Nozzles recomended. . . . . . . . . . . . . . . . 6
4.3 Electrode setting . . . . . . . . . . . . . . . . . . . 7
4.4 Combustion head setting. . . . . . . . . . . . . 7
4.5 Air damper adjustment . . . . . . . . . . . . . . 7
4.6 Pump pressure . . . . . . . . . . . . . . . . . . . . 8
4.7 Burner start-up cycle. . . . . . . . . . . . . . . . 8
4.8 Adjustments, to avoid flame - detachment,
at burner - ignition . . . . . . . . . . . . . . . . . . 8
5. MAINTENANCE . . . . . . . . . . . . . . . . . . . 9
6. FAULTS / SOLUTIONS . . . . . . . . . . . . . . 10
■
The burner meets protection level of IP 40, EN 60529.
■
Burner with CE marking in conformity with EEC directives: EMC 89/336/EEC, Low Voltage 73/23/EEC,
Machines 98/37/EEC and Efficiency 92/42/EEC.
1 – Oil pump
2 – Control-box
3 – Reset button with lock-out lamp
4 – Hydraulic jack with air-damper
5 – Screws fixing air-damper
6 – Flange with insulating gasket
7 – Combustion head adjustment screw
8 – Grommet
Fig. 1
D1855
1
2
3
4
7
6
5
5
8
