Simmons City Sleeper - Page 9

9
Customer Service: (646) 435-8726 www.DeltaChildren.com
Canopy
Attachment Holes
Clip on Mobile Arm
Attachment Joints
Fig. 1B
Top Support Tube
Zipper pull
tab slider
3
Place the front bassinet fabric over the front rail tube. Align
and fasten zipper to top rail (Fig. 1B) until fully zipped.
4
Stretch the pockets on the bottom of the fabric liner
around the ends of the mattress support board.
Snaps
Mattress Support Board
Pocket
5
Locate the four (4) snaps on the underside of the
mattress support board and snap them in.
FABRIC LINER ASSEMBLY
BACK
START
END
FRONT
NOTE: One side of the fabric liner has the canopy attachment
holes and should face the opposite side of the clip on mobile arm
attachment joints.
Pocket
