congratulations
TOM 4 CRASH 2
MIDI OUT MIDI IN
SD
Cymbal Pads
Tom Pads
Hi-Hat Cymbal Pad
Snare Pad
Tom Pad
Drum Module
Kick Pad
Hi-Hat Control Pedal
You’ve successfully assembled your new Simmons SD1000 Electronic Drum Kit.
For connection instructions and more information on your new kit, please refer to
the User Manual, or visit www.simmonsdrums.net
BASS DRUM, HI-HAT PEDAL and Pad Connections
SD ELECTRONIC DRUM KIT ASSEMBLY SHEET
www.simmonsdrums.net
Place the bass drum pad on the floor in the center
of the rack as illustrated.
Attach your bass drum pedal to the bass drum pad
(pedal not included).
Place the hi-hat pedal on the floor and to the left,
as illustrated below.
Connect the marked cables from the pads to
their corresponding inputs on the drum module.
3
4
1
2
Simmons_SD1000_Assembly_Instructions.indd 1 5/9/13 3:24 PM
