SIMONINI Victor 2 Plus User Manual

M6
GEAR BOX OIL LEVEL INDICATOR
10NM
-
GEAR BOX OIL FILTER / HEAT DISSIPATER
20NM
-
GEAR BOX OIL DRAIN PLUG
20NM
15. WEAR LIMITS:
PISTONS WITH NEW CYLINDERS AT ASSEMBLY
0.06 -0.07 mm
WEAR LIMIT BETWEEN CYLINDER AND PISTON
0.12 mm
MAXIMUM CYLINDER CONICAL LEVEL
0.04 mm
MAXIMUM OVALISATION
0.04 mm
DATUM POINT TO MEASURE PISTON IS 12/13 mm FROM
MANTLE BASE
DRIVE SHAFT NEW AT ASSEMBLY OUT OF CENTRE
0.01 mm
DRIVE SHAFT USED, AT ASSEMBLY AFTER SERVICE
0.04 mm
AXIAL CRANKSHAFT CLEARANCE
0.04 mm
RESILIENT RUBBER "DONUT" AT ASSEMBLY
0.35-0.40mm
