4 S4100-0103 5/2013
Transponder Type
Model Description Supv. Alarm
4100-9600
Basic Transponder, includes bay equipment with power distribution interface, and 4100-0620 Basic
Transponder Interface Module mounted in Block A
87 mA 87 mA
4100-9601
Local Mode Transponder, includes bay equipment with power distribution interface, and
4100-0625 Local Mode Transponder Interface Module mounted in Block A
normal 87 mA 87 mA
in local mode 112 mA 112 mA
Local Mode Controller Selection
Model Description Supv. Alarm
4601-9108 Flush mount
Red with white
lettering
Local Mode Controller, 3-gang plate mounted;
flush mount requires a 1 ½” (38 mm) deep
3-gang box; surface mount controllers include a
matching mounting box; see p. 7 for details
normal 12 mA 12 mA
4601-9109 Surface mount
4601-9110 Flush mount
Beige with black
lettering
in local mode 20 mA 60 mA
4601-9111 Surface mount
Communication Modules
Model Description Size Supv. Alarm
4100-6031
Select one per
EPS+ or EPS
City Circuit, with disconnect switches N.A. 20 mA 36 mA
4100-6032 City Circuit, without disconnect switches N.A. 20 mA 36 mA
4100-6033 Alarm Relay, 3 Form C relays, 2 A @ 32 VDC N.A. 15 mA 37 mA
4100-6038 Dual RS-232 Interface 1 Slot 132 mA 132 mA
4100-6045 Decoder Module 3 Slots 85 mA 163 mA
4100-6048 VESDA Aspiration System Interface 1 Slot 132 mA 132 mA
4100-9816 Master Clock Interface Module with one standard RS-232 port (see S4100-0033) 1 Slot 132 mA 132 mA
Enhanced and Expansion Power Supplies and Accessories (see specification details on page 6)
Model Voltage/Listing Description Size Supv. Alarm
4100-5311 120 VAC
UL &
ULC
Enhanced Power Supply (EPS+); 9 A Enhanced Power
Supply/battery charger with 250 point IDNet 1+ interface,
3 Class B IDNAC SLCs, RUI+ isolated output communications
interface, and auxiliary relay; 120 VAC model has selectable
low battery cutout
4 Blocks
Right
Side
217 mA 480 mA
4100-5313 220-240 VAC UL
with 200 IDNet
devices and 20
device LEDs in alarm
4100-5325 120 VAC
UL &
ULC
Enhanced Power Supply (EPS); 9 A Enhanced Power
Supply/battery charger with 3 Class B IDNAC SLCs, RUI+
isolated output communications interface, and auxiliary relay;
120 VAC model has selectable low battery cutout
4 Blocks
Right
Side
125 mA 220 mA
4100-5327 220-240 VAC UL
4100-6103
Dual Class A IDNAC Isolator (DCAI), converts a single Class B IDNAC SLC input to two
Class A or two Class B SLC outputs; provides short circuit isolation between each Class A
or B output circuit; connect up to two DCAI modules per IDNAC SLC input up to a
maximum of 6 DCAI modules per EPS; each isolated output SLC used requires one IDNAC
address; the total current remains controlled by the Class B input source SLC at 3 A
maximum
1 Block 6.5 mA 6.5 mA
Model Voltage/Listing Description Size Supv. Alarm
4100-5101 120 VAC UL
Expansion Power Supply (XPS); 9 A output, 3 built-in
Class A/B NACs, rated 3 A for Special Application
appliances (2 A for Regulated DC); NACs can be selected
as auxiliary power outputs, derated to 2 A for continuous
duty, total per XPS is 5 A; 4100-5103 has low battery cutout
2 Blocks 50 mA 50 mA
4100-5103 120 VAC, Canadian ULC
4100-5102 220-240 VAC UL
4100-5115 NAC Expansion Module, 3 NACs, Class A/B, mounts on XPS only N.A. 25 mA 25 mA
4100-5152 12 VDC Power Option, 2 A maximum 1 Block 1.5 A maximum
4100-0636 Box Interconnection Harness Kit (non-audio); order one for each close-nippled cabinet
Miscellaneous Options and Accessories
Model Description
4100-1290
24 Point I/O Module for external connections, select each point as either a switch input (momentary or maintained) or an
output (for lamp/LED/relay); requires 1 Slot (refer to data sheet S4100-0032 for additional information)
4100-0632 Terminal Block Utility Module with 2, 16 position terminal blocks on 4” x 5” single block, for of up to 12 AWG wire (3.31 mm
2
)
4100-0633 Door Tamper Switch, connects into Transponder Interface Module, one per cabinet assembly if required
4100-0634 120 VAC
Power Distribution Module (PDM) select per system voltage; one required per box
4100-0635 220/230/240 VAC
4100-9837 Green LED Power-on Indicator Kit, required for ULC listing of MINIPLEX transponder; mounts on solid door knockout
2081-9031
Series resistor for WSO, IDCs (N.O. water flow and tamper on same circuit, wires after water flow and before tamper) 470 Ω,
1 W, encapsulated, two 18 AWG leads (0.82 mm
2
), 2 ½” L x 1 ⅜” W x 1” H (64 mm x 35 mm x 25 mm)
* Standard power supply NACs can provide synchronized strobe or SmartSync, two-wire operation. Continued on next page
MINIPLEX Transponder Product Selection
