Simpli Home ARTISAN - Page 11

/1811
STEP-6
ASSEMBLY
MODEL # AXCART21-WH
2
2. Insert three Cam Locks 2 into guide holes on
each part D , E .
3.
Use Phillips screwdriver to secure Cam Locks. Do not over-tighten
1. Align Cam Lock Pin with guide holes on
parts D , E and attach Right Side BR
to parts D , E .
Front / Avant
Front / Avant
Front / Avant
Front / Avant
Front / Avant
E
D
D
BR
BR
E
D
D
