Specifications
DIMENSIONS
36" Snowthrower
42" Snowthrower
Effective Width:
36 In. (914 mm)
42 In. (1067 mm)
Overall Width:
37-1/2 In. (953 mm)
43-1/2 In. (1105 mm)
Overall Length:
27 In. (686 mm)
27 In. (686 mm)
Opening Height:
19 In. (483 mm) 19 In. (483 mm)
Auger Diameter:
12 In. (305 mm)
12 In. (305 mm)
CONTROLS
Auger Drive: V-belt and auger chain.
Raise & Lower: Spring assisted tractor lift
lever or optional electric lift or hydraulic lift.
Spout Rotation: Tee Handle to right of operator or optional electric spout rotator.
DRIVE TRAIN
Input Drive: Cushioning V-belt
Final Drive: Enclosed Roller Chain
CHASSIS
Auger Bearings: Self-aligning roller contact with lube fitting
Housing: Welded steel channel and stamping
Scraper Bar: Full width high carbon steel - Replaceable
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Table of Contents
IDENTIFICATION. Inside Front Cover
ACCESSORIES . Inside Front Cover
SPECIFICATIONS . 1
SAFETY RULES . 2
SAFETY DECALS . 3
INSTALLATION & REMOVAL . 4
INSTALLATION . 4
REMOVAL. 6
OPERATION . 8
CONTROLS . 8
CHECK BEFORE STARTING . 8
TRANSPORTING . 8
ENGINE SPEED & GEAR SELECTION . 8
SNOW REMOVAL SUGGESTIONS . 9
NORMAL CARE . 1 0
SCHEDULED CARE .10
NORMAL STORAGE .10
OFF-SEASON STORAGE .10
DRIVE CHAIN .11
TROUBLESHOOTING .12
ADJUSTMENTS .13
SKID SHOE ADJUSTMENT .13
DRIVE BELT TENSION .13
LIFT ROD ADJUSTMENT .14
ASSEMBLY.15
ASSEMBLY.15
WINTERIZING THE TRACTOR .18
TIRE CHAIN INSTALLATION .23
DECAL INSTALLATION .24
STANDARD FASTENER IDENTIFICATION CHART. Inside Back Cover
