Installation & Removal
5. Remove the belt from the PTO pulley (A, figure 5)
and from the two idler pulleys (B & C). If a mower
attachment is to be used on the tractor, remove the
front idler pulley (D, figure 4) and install it in upper
tab.
6. Remove the snowthrower from the tractor by using
either one of the following methods “a” or “b”. (The
belt may remain on snowthrower pulley unless
removal is desired for storage.)
a. Remove the two pins and spring clips (C and D,
figure 11) from snowthrower clips (E), remove the
snowthrower clips (E), then remove the
snowthrower. Remove the two pins and spring
clips (C and D) that secure snowthrower hitch,
then remove it from the tractor hitch.
b. Remove the two pins and spring clips that secure
snowthrower hitch (A, figure 11) to tractor hitch
(B). Remove the snowthrower and hitch by
pulling up and away from tractor hitch.
7. To use tractor without snowthrower, decrease tire
pressure to normal psi (see tractor Operator’s
Manual).
Figure 11. Attach Snowthrower
A. Snowthrower Hitch
B. Tractor Hitch
C. Pin
D. Spring Clip
E. Clip
