Simplicity 1692380

9 Hydro Transmission Repair
Hydro-Gear 310-0500
9-2
Figure 2 Hydro Gear Model 750 Hydrostatic Transaxle
Hook on screw
located on upper
housing assembly.
Hook end of
spring (16) on
screw located
here.
