Simplicity 1692380 Service & Repair Manual

Section Description Start Page End Page
1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 — 1-14
2 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 — 2-4
3 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 — 3-10
4 Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1 — 4-8
5 Electrical Troubleshooting. . . . . . . . . . . . . . . . . . . 5-1 — 5-18
6 Wheel Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1 — 6-4
7 Foot Controls Repair . . . . . . . . . . . . . . . . . . . . . . . . . 7-1 — 7-8
8 Hand Controls Repair . . . . . . . . . . . . . . . . . . . . . . . . 8-1 — 8-10
9 Hydro Transmission Repair . . . . . . . . . . . . . . . . . 9-1 — 9-20
10 Gear Transmission Repair. . . . . . . . . . . . . . . . . . . 10-1 — 10-8
11 Belt & Clutch Replacement . . . . . . . . . . . . . . . . . 11-1 — 11-6
12 Mower Deck Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-1 — 12-22
Repair Manual Contents
This manual is divided into the sections listed below.
Please see the first page of each section for the specific contents of that section.

Simplicity 1692380 Specifications

General

Brand	Simplicity
Model	1692380
Category	Lawn Mower
Language	English
