9-9
9 Hydro Transmission Repair
Hydro-Gear 310-0500
1 1 BREATHER ASSY.
2 1 BUSHING, Rubber
3 1 ARM, Bypass
4 1 SEAL
5 2 PUCK, Dampener
6 1 SET SCREW
7 1 ARM, Control
8 1 SPRING
9 1 CUP WASHER
10 1 SCREW, Socket Hd.
11 2 ACTUATOR PIN
12 1 ARM, Brake
13 1 WASHER, 7/16 x 7/8 x 1/16
14 1 LOCKING STRAP
15 1 NUT, Hex, Lock, 5/16 x 24
16 1 SEAL, Lip
17 1 SEAL, Lip
18 1 RING, Retaining
Ref. Qty. Description Ref. Qty. Description
NOTE: These parts are used on transmissions with S/N’s prior to 4000T0001.
1 1 BREATHER ASSY.
2 1 BUSHING, Rubber
3 1 ARM, Bypass
4 1 SEAL
5 1 SET SCREW
6 2 ACTUATOR PIN
7 1 ARM, Brake
8 3 WASHER, 7/16 x 7/8 x 1/16
9 2 NUT, Hex, Lock, 5/16 x 24
10 1 SEAL, Lip
11 1 SEAL, Lip
12 1 RING, Retaining
13 1 CASTLE NUT, 5/16-24
14 2 PUCK, Dampener
15 1 ARM, Control
16 1 SPRING
17 1 SPACER
18 1 STUD, 5/16-24
19 1 SPRING, Helical Compression
20 1 COTTER PIN
Ref. Qty. Description Ref. Qty. Description
NOTE: These parts are used on transmissions with S/N’s 4000T0001 and higher.
Remove External Components & Linkages
1. Remove the input pulley.
2. Remove all external linkages including those pictured
in Figure 5.
