SIMPLIHOME Lowry - Step 9: Attaching Back Panels

Step 9
Front /
Avant
Front /
Avant
Note:
The back of the tv frame does not have pre-drilled holes to attach the back panels.
Warning Label
A
H
3
H
I
Front /
Avant
Front /
Avant
A
3
1. Attach the Back Panels H , I to back frame
using Phillips Screws Round Head 3 through guide holes.
2. Use Phillips Screwdriver to tighten screws. Do not over-tighten.
19
Model # AXCLRY42-DCBAssembly
