Step 10
6
7
GL
GR
1. Attach Adjustable Hinges 6 to Doors GL , GR using
Phillips Screws 7 into guide holes on Doors GL , GR .
2. Attach Adjustable Hinges 6 on Doors GL , GR to Sides BL , BR using Phillips
Screws 7 into guide holes on Sides BL , BR .
3. Attach Magnets 4 using Phillips Screws 5 into guide holes on Divider E .
4. Attach Magnet Plates 4 to top corner of Doors GL , GR using Phillips Screws 5 into
pre-drilled holes on Doors GL , GR .
5. Use Phillips screwdriver to snugly tighten screw.
5
5
5
4
6
7
GL
GR
BR
BL
GL
GR
E
20
Model # AXCLRY42-DCBAssembly
