2
Step 1
The bath screen should be positioned centrally or slightly toward the inside
of the bath rim, as shown. Place the wall channel in position on the bath
and against the wall, use a spirit level to ensure it is vertical and mark all 3
fixing holes onto the walls.
Drill holes in the positions marked using a 6mm masonry drill bit. Insert
wall plugs (C) into all of the holes (beyond the thickness of the tile). Fix the
wall channel to the wall using 3 x 50mm screws (B).
Note: Inject silicone sealant into the holes before inserting the screws to
seal the holes.
Remove the water seal (D) from the front edge of the
glass and push fit onto the bottom of the bath screen.
Ensure the seal is flush with the back edge of the
glass. If necessary, trim the seal using scissors to get
a good fit against the black seal.
Step 2
Ø 6mm
BATH SCREEN
Inside
