The manufacturer reserves the right to make
technical modifications without prior notice.
Step 4
Sealing: On the inside and outside, run a line of
silicone sealant from top to bottom down the joint
between the wall channel and tiles.
Step 3
With help, push the bath screen fully onto the wall channel.
Check that the fitted water seal brushes the edge of the bath evenly along
its length. From inside, drill 3 holes through the wall channel into the bath
guard (in the marked positions) using a 3mm drill bit.
Note: Stop drilling as soon as you feel the drill break through the first
layers of aluminium.
Fix using 3 x 10mm screws (A).
Outside only: Run a line of silicone sealant along the
joint between the bottom edge of the wall channel and
bath rim.
Inside
Outside
Inside
Ø 3mm
