Wiring
CAN BUS (NMEA 2000)
A
Male Micro-C drop cable 1.8 m
(6 ft) cable
B Micro-C T-connector
C
CAN BUS (NMEA 2000)
backbone
¼ Note: NMEA 2000® and the NMEA 2000 logo are registered
trademarks of the National Maritime Electronics Association.
Compliance Statements
OP50 controller:
• complies with CE under EMC directive 2014/30/EU
• complies with the requirements of level 2 devices of the
Radiocommunications (Electromagnetic Compatibility) standard
2008
