6 |
7. Repeat step 3 and 4 until all MFDs are assigned to a LED
8. Press the X key to save your settings and return to normal operation
Unassigning an MFD from an OP50
1. Press and hold the DISP key on the OP50 for 5 seconds to enter
OP50 configuration mode
- All LEDs on the OP50 turn red to indicate that the OP50 is in
configuration mode.
- The configuration dialog is displayed on all MFDs.
2. Use the rotary knob to select the MFD that is to be unassigned
- Selected MFD is identified with a border.
3. Select the Unassign button, or press the MENU key and select the
Unassign option
4. Press the X key to save your settings and return to normal operation
Conguring the next OP50
Press and hold the DISP key for 1 second to take command of
another OP50 in configuration mode.
Selecting which MFD to control
Press the DISP key to toggle through the LEDs.
Once a LED has red steady light the OP50 is in control of the MFD
assigned to that LED.
The MFD controlled by the OP50 has a small icon on the screen.
OP50 LEDs
Status Description
Off
The OP50 is not powered, or no MFD is
assigned to the LED position.
Flashing
The MFD assigned to the LED position is
not active (either Off or still switching On).
Steady
The MFD assigned to the LED position is
ON and ready for OP50 control.
All LEDs Steady The OP50 is in configuration mode.
DISP
1 2 3 654
