Simu Hz 2 - Page 16

Hz Wireless Switches
and Receivers
R
Switch Style & Programming Button Location Reference Description
6301066
6301070
6301071
6301090
White
6301091
Ivory
6301080
White
6301081
Ivory
6301075
6301072
Slim Single Channel Hand Held
-Available in white
Recessed Designer Single Channel
-Available in white and ivory
Hz Radio Receiver Motor Controller
-This radio receiver can be used with the SIMU
standard AC motor series 120v-60hz. This control
is compatible with all the transmitter switches
shown above.
Hz Dry Contact Interface Transmitter
-This radio transmitter can be used with the SIMU
Hz operator series 120v-60hz. This interface control
is compatible most A/V system hook-ups.
Recessed Designer Multi Channel
-5 independent channels that can be programmed
to operate one or more motors.
-Available in white and ivory
Slim Multi Channel Hand Held
-5 independent channels that can be programmed
to operate one or more motors.
-Available in white
Single Channel Surface Wall Mount
-Available in white
Program Button
Program Button
FCC
Label
CF C
Label
BACK OF TRANSMITTER
BACK OF TRANSMITTER
Program Button
SIDE OF TRANSMITTER
SIDE OF TRANSMITTER
Program Button
Program Button
TRANSMITTER CORE
(INSIDE CASE)
Programming Button & LED
UP
DOWN
MTR COM
NEUT
HOT
H ER
z
R
ECEIV
/120 VA
C
6 H
z 0
6:
301
0R
EF 7
5
H
y
C
t t fz D on
a
tI n
e ace
r c r
RF
:
6301
0
72
E
Programming Button & LED
DOWN
STOP
COM
UP
Battery
White
Black
Red
Green
