SINAMICS G120 - Page 108

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Supplementary system components
PC Inverter Connection Kit -2
4/108
Siemens D 11.1 · 2009
4
■ Overview
For controlling and commissioning an inverter directly from a PC,
if the STARTER commissioning tool has been installed on the PC.
With these, the inverter can be
• parameterized (commissioning, optimization)
• monitored (diagnostics)
• controlled (master control via the STARTER commissioning
tool for test purposes).
A USB cable (3 m) and the STARTER commissioning tool
1)
are
included as scope of delivery on a DVD.
■ Selection and ordering data
■ Overview
Example: PC Connection Kit for CU240 Control Units
For controlling and commissioning an inverter directly from a PC,
if the STARTER commissioning tool has been installed on the PC.
With these, the inverter can be
• parameterized (commissioning, optimization)
• monitored (diagnostics)
• controlled (master control via the STARTER commissioning
tool for test purposes).
This is an isolated RS232 adapter board for a reliable point-to-
point connection to a PC with a serial RS232 interface. A
USB/RS232 adapter can be used as an alternative (e.g. type
12.02.1086R supplied by Roline).
The scope of delivery includes a 9-pin Sub-D connector, an
RS232 standard cable (3 m) and the STARTER commissioning
tool
1)
on DVD.
■ Selection and ordering data
Order No.
PC Inverter Connection Kit -2
for CU230P-2 Control Units
Including USB cable (3 m) and
STARTER commissioning tool
1)
on DVD
6SL3255-0AA00-2CA0
new
Order No.
PC Inverter Connection Kit
Including a 9-pin Sub-D connector, an RS232
standard cable (3 m), and the STARTER
commissioning tool
1)
on DVD
6SL3255-0AA00-2AA1
1)
The STARTER commissioning tool is also available in the Internet under
http://support.automation.siemens.com/WW/view/en/10804985/133100
Supplementary system components
PC Inverter Connection Kit
© Siemens AG 2009
