SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
PM240 Power Modules –
0.37 kW to 250 kW (0.5 hp to 400 hp)
4/33
Siemens D 11.1 · 2009
4
■
Integration
Power and DC link components which are optionally avail-
able depending on the Power Module used
The following line-side power components, DC link components
and load-side power components are optionally available in the
appropriate frames sizes for the Power Modules:
U = Base component
S = Lateral mounting
I = Integrated
– = Not possible
F = Power Modules available with and without integrated class A filter
Frame size
FSA FSB FSC FSD FSE FSF FSGX
PM240 Power Module with integrated brake chopper without inte-
grated brake
chopper
Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓
Line-side power components
Line filter, class A U F F F F F/S
1)
S
1)
Line filter, class B U U U – – – –
Line reactor U U U U U S S
DC link components
Braking resistor U U S S S S S
Braking Module – – – – – – I (Option)
Load-side power components
Output reactor U U U S S S S
Sine-wave filter U U U S S S S
1)
PM240 FSF Power Modules from 110 kW (150 hp) and higher and FSGX
are only available without an integrated class A filter. An optional class A
line filter for side mounting is available instead.
