SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
PM240 Power Modules –
0.37 kW to 250 kW (0.5 hp to 400 hp)
4/37
Siemens D 11.1 · 2009
4
Technical specifications
Line supply voltage
380…480V 3AC
PM240 Power Modules
Without integrated line filter 6SL3224-
0BE13-7UA0
6SL3224-
0BE15-5UA0
6SL3224-
0BE17-5UA0
6SL3224-
0BE21-1UA0
6SL3224-
0BE21-5UA0
Output current
at 50 Hz 400 V 3 AC
Rated current I
rated
1)
A 1.3 1.7 2.2 3.1 4.1
Base load current I
L
1)
A 1.3 1.7 2.2 3.1 4.1
Base load current I
H
2)
A 1.3 1.7 2.2 3.1 4.1
I
max
A 2.6 3.4 4.4 6.2 8.2
Rated power
based on I
L
kW (hp) 0.37 (0.5) 0.55 (0.75) 0.75 (1.0) 1.1 (1.5) 1.5 (2.0)
based on I
H
kW (hp) 0.37 (0.5) 0.55 (0.75) 0.75 (1.0) 1.1 (1.5) 1.5 (2.0)
Rated pulse frequency kHz 4 4 4 4 4
Efficiency
η
0.97 0.97 0.97 0.97 0.97
Power loss
(at rated current)
kW 0.09 0.1 0.1 0.1 0.11
Cooling air requirement m
3
/s 0.005 0.005 0.005 0.005 0.005
Sound pressure level L
pA
(1 m)
dB <45 <45 <45 <45 <45
24 V DC power supply
for Control Unit
A 1 1 1 1 1
Rated input current
3)
with line reactor A 1.4 1.8 2.3 3.2 4.3
without line reactor A 1.7 2.1 2.6 3.9 4.9
Max. length of cable to
brake resistor
m 15 15 15 15 15
Line supply connection
U1/L1, V1/L2, W1/L3
Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals
Conductor cross-section mm
2
1…2.5 1…2.5 1…2.5 1…2.5 1…2.5
Motor connection
U2, V2, W2
Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals
Conductor cross-section mm
2
1…2.5 1…2.5 1…2.5 1…2.5 1…2.5
DC link connection,
connection for the braking
resistor
DCP/R1, DCN, R2
Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals
Conductor cross-section mm
2
1…2.5 1…2.5 1…2.5 1…2.5 1…2.5
PE connection On housing with
M4 screw
On housing with
M4 screw
On housing with
M4 screw
On housing with
M4 screw
On housing with
M4 screw
Motor cable length
4)
, max.
Shielded m 50 50 50 50 50
Unshielded m 100 100 100 100 100
Degree of protection IP20 IP20 IP20 IP20 IP20
Dimensions
Width mm 73 73 73 73 73
•Height mm 173 173 173 173 173
•Depth
- without Control Unit mm 145 145 145 145 145
- with Control Unit mm 210 210 210 210 210
Frame size FSA FSA FSA FSA FSA
Weight, approx. kg 1.1 1.1 1.1 1.1 1.1
1)
The rated output current I
rated
and the base load current I
L
are based on
the duty cycle for light overload (LO).
2)
The base load current I
H
is based on the duty cycle for high overload (HO).
3)
The input current depends on the motor load and line impedance. The
input currents apply for a load at rated power (based on I
rated
) for a line
impedance corresponding to u
K
= 1 %. These current values without line
reactor are stamped on the rating plate of the Power Module.
4)
Max. motor cable length 25 m (shielded) for PM240 Power Modules with
integrated line filter to maintain the limit values of EN 61800-3 Category C2.
