SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
PM240 Power Modules –
0.37 kW to 250 kW (0.5 hp to 400 hp)
4/43
Siemens D 11.1 · 2009
4
■ Characteristic curves
Ambient temperature
High overload (HO) PM240 Power Modules frame sizes FSD to FSF
High overload (HO) PM240 Power Modules frame size FSGX
Light overload (LO) PM240 Power Modules frame sizes FSD to FSF
Light overload (LO) PM240 Power Modules frame size FSGX
Note: The operating temperature ranges of the Control Units
should be taken into account. The temperature ranges are spe-
cified in the technical specifications under Control Units.
Installation altitude
0 20 30 10 40
-10 50 C° 60
75
%
50
25
100
74
G_D011_EN_00111
Ambient temperature
Permissible output current
0 20 30 10 40
-10 50 C°55
75
%
50
25
100
85
G_D011_EN_00213
Ambient temperature
Permissible output current
0 20 30 10 40
-10 50 C° 60
75
%
50
25
100
66
G_D011_EN_00110
Ambient temperature
Permissible output current
0 20 30 10 40
-10 50 C°55
75
%
50
25
100
85
G_D011_EN_00213
Ambient temperature
Permissible output current
80
100
%
0 1000 2000 3000 4000 m
70
90
60
G_D011_EN_00104
Installation altitude above sea level
Permissible output current
80
100
%
0 1000 2000 3000 4000 m
77
70
90
60
G_D011_EN_00105
Installation altitude above sea level
Permissible input voltage
