SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
PM250 Power Modules –
7.5 kW to 75 kW (10 hp to 100 hp)
4/57
Siemens D 11.1 · 2009
4
Technical specifications
Line supply voltage
380…480V3AC
PM250 Power Modules
Without integrated line filter 6SL3225-0BE31-5UA0 6SL3225-0BE31-8UA0 6SL3225-0BE32-2UA0
With integrated line filter 6SL3225-0BE31-5AA0 6SL3225-0BE31-8AA0 6SL3225-0BE32-2AA0
Output current at
50 Hz 400 V 3 AC
Rated current I
rated
1)
A 38 45 60
Base load current I
L
1)
A 38 45 60
Base load current I
H
2)
A 32 38 45
I
max
A 64 76 90
Rated power
based on I
L
kW (hp) 18.5 (25) 22 (30) 30 (40)
based on I
H
kW (hp) 15 (20) 18.5 (25) 22 (30)
Rated pulse frequency
kHz 4 4 4
Efficiency
η
>0.97 >0.97 >0.97
Power loss
(at rated current)
kW 0.42 0.52 0.68
Cooling air requirement m
3
/s 0.022 0.022 0.039
Sound pressure level L
pA
(1 m)
dB <60 <60 <61
24 V DC power supply for
Control Unit
A 1 1 1
Input current
3)
Rated current A 36 42 56
based on I
H
A 30 36 42
Line supply connection
U1/L1, V1/L2, W1/L3
M6 screw studs M6 screw studs M6 screw studs
Conductor cross-section mm
2
10 35 10 35 10 35
Motor connection
U2, V2, W2
M6 screw studs M6 screw studs M6 screw studs
Conductor cross-section mm
2
10 35 10 35 10 35
PE connection On housing with M6 screw On housing with M6 screw On housing with M6 screw
Motor cable length, max.
4)
Shielded m 50 50 50
Unshielded
m 100 100 100
Degree of protection
IP20 IP20 IP20
Dimensions
Width mm 275 275 275
•Height
- without integrated line filter mm 419 419 419
- With integrated line filter mm 512 512 512
•Depth
- without Control Unit mm 204 204 204
- with Control Unit mm 260 260 260
Frame size FSD FSD FSD
Weight, approx.
Without integrated line filter kg 13 13 13
With integrated line filter kg 15 15 16
1)
The rated output current I
rated
and the base load current I
L
are based on
the duty cycle for light overload (LO).
2)
The base load current I
H
is based on the duty cycle for high overload (HO).
3)
The input current depends on the motor load and is valid for a line impe-
dance corresponding to u
K
= 1 %. The rated input currents apply for a
load at the rated power (based on I
rated
) – these current values are speci-
fied on the rating plate.
4)
Max motor cable length 25 m (shielded) for PM250 Power Modules with
integrated line filter to maintain the limit values of EN 61800-3 Category C2.
