SINAMICS G120 - Page 67

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
PM260 Power Modules –
11 kW to 55 kW (15 hp to 75 hp)
4/67
Siemens D 11.1 · 2009
4
■ Integration
Power and DC link components which are optionally avail-
able depending on the Power Module used
The following line-side power components, DC link components
and load-side power components are optionally available in the
appropriate frame sizes for the Power Modules:
I = Integrated
– = Not possible
F = Power Modules available with and without integrated class A filter
Maximum permissible cable lengths from the motor to the
inverter when using output reactors or sine-wave filters
depending on the voltage range
The following load-side power components in the appropriate
frame sizes are optionally available for the Power Modules and
result in the following maximum cable lengths:
Frame size
FSA FSB FSC FSD FSE FSF FSGX
PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter
Available frame sizes – – – ✓ – ✓ –
Line-side power components
Line filter, class A – – – F – F –
Line filter, class B – – – – – – –
Line reactor
1)
– – – –
1)
– –
1)
–
DC link components
Braking resistor
2)
– – – –
2)
– –
2)
–
Load-side power components
Output reactor – – – – – – –
Sine-wave filter – – – I – I –
Maximum permissible motor cable lengths (shielded/unshielded) in m
Frame sizes
FSA FSB FSC FSD FSE FSF FSGX
PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter
Available frame sizes – – – ✓ – ✓ –
With integrated sine-wave filter
• at 500 V to 690 V 3 AC (±10 %) – – – 200/300 – 200/300 –
1)
A line reactor is not required and must not be used in conjunction with a
PM250 or PM260 Power Module.
2)
Line-commutated energy recovery is possible in conjunction with a PM250
or PM260 Power Module. A braking resistor cannot be connected and is
not necessary.
© Siemens AG 2009
