SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
PM260 Power Modules –
11 kW to 55 kW (15 hp to 75 hp)
4/68
Siemens D 11.1 · 2009
4
■
Technical specifications
General technical specifications
PM260 Power Modules
System operating voltage
500 … 690 V 3 AC ±10 %
For operation from 500 V –10 % linearly reduced – see derating characteristics
Line supply requirements
Line short circuit voltage u
K
≤ 1%
Input frequency 47 … 63 Hz
Output frequency
• Control type V/f 0…200Hz
• Control type Vector 0…200Hz
Pulse frequency 16 kHz (standard)
Power factor 0.95
Inverter efficiency 95 … 97 %
Modulation depth
87 %
Overload capability
• High overload
(HO)
1.5 × rated output current (i.e. 150 % overload ) for 57 s with a cycle time of 300 s
2 × rated output current (i.e. 200 % overload) for 3 s with a cycle time of 300 s
• Light overload
(LO)
1.1 × rated output current (i.e. 110 % overload ) for 57 s with a cycle time of 300 s
1.4 × rated output current (i.e. 140 % overload) for 3 s with a cycle time of 300 s
Electromagnetic compatibility Optional class A line filter according to EN 55011 is available
Possible braking methods Energy recovery in the generator mode
Degree of protection IP20
Operating temperature
• High overload
(HO)
0 … 50 °C (32 … 122 °F) without derating,
> 50 … 60 °C see derating characteristics
• Light overload
(LO)
0 … 40 °C (32 … 104 °F) without derating,
> 40 … 60 °C see derating characteristics
Storage temperature –40…+70°C (–40…+158°F)
Relative humidity < 95 % RH, condensation not permissible
Cooling Internal air cooling,
power units with increased air cooling using integrated fans
Installation altitude up to 1000 m above sea level without power reduction,
> 1000 m see derating characteristics
Standard SCCR (S
hort Circuit Cur-
rent R
ating)
1)
42 kA
Protection functions
• Undervoltage
• Overvoltage
• Overcontrol/overload
• Ground fault
• Short circuit
• Stall protection
• Motor blocking protection
• Motor overtemperature
• Inverter overtemperature
• Parameter locking
Standards conformance CE
CE mark According to Low-Voltage Directive 73/23/EEC and Machinery Directive 98/37/EC
1)
Applies to industrial control cabinet installations to NEC Article
409/UL 508A. For further information, visit us on the Internet at:
http://support.automation.siemens.com/WW/view/en/23995621
