SINAMICS G120 - Page 76

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Line-side power components
Line filters
4/76
Siemens D 11.1 · 2009
4
■ Technical specifications
Line supply voltage
380…480V3AC
Line filter class A
6SE6400-2FA00-6AD0 6SL3203-0BE32-5AA0 6SL3000-0BE34-4AA0 6SL3000-0BE36-0AA0
Rated current A 6 250 440 600
Line supply connection
L1, L2, L3
Screw terminals On housing with
M8 screw studs
1 × hole for M10
Provided for busbar
connection
1 × hole for M10
Provided for busbar
connection
• Conductor cross-section mm
2
2.5 – – –
Load connection
U, V, W
Shielded cable On housing with
M8 screw studs
On housing with
M10 screw studs
On housing with
M10 screw studs
• Conductor cross-section mm
2
3 × 2.5 – – –
•Length m 0.4 – – –
PE connection On housing with
M4 screw studs
Flat connector for
M10 screw
1 × hole for M8 1 × hole for M10
Degree of protection IP20 IP00 IP00 IP00
Dimensions
• Width mm 73 240 360 400
•Height mm 200 360 240 265
•Depth mm 42.5 116 116 140
Possible as base component yes no no no
Weight, approx. kg 0.5 12.4 12.3 19
Suitable for
PM240 Power Module
Type 6SL3224-0BE13-7UA0
6SL3224-0BE15-5UA0
6SL3224-0BE17-5UA0
6SL3224-0BE21-1UA0
6SL3224-0BE21-5UA0
6SL3224-0BE38-8UA0
6SL3224-0BE41-1UA0
6SL3224-0XE41-3UA0
6SL3224-0XE41-6UA0
6SL3224-0XE42-0UA0
Suitable for
PM250 Power Module
– – – –
Frame size FSA FSF FSGX FSGX
Line supply voltage
380…480V3AC
Line filter class B
6SE6400-2FB00-6AD0 6SL3203-0BE21-6SA0 6SL3203-0BD23-8SA0
Rated current A 6 10.2 39.4
Line supply connection
L1, L2, L3
Screw terminals Screw terminals Screw terminals
• Conductor cross-section mm
2
2.5 2.5 4
Load connection
U, V, W
Shielded cable Shielded cable Shielded cable
• Conductor cross-section mm
2
3 × 2.5 3 × 2.5 3 × 4
•Length m 0.4 0.4 0.4
PE connection On housing with
M4 screw studs
On housing with
M4 screw studs
On housing with
M4 screw studs
Degree of protection IP20 IP20 IP20
Dimensions
• Width mm 73 153 190
•Height mm 200 296 362
•Depth mm 42.5 50 55
Possible as base component yes yes yes
Weight, approx. kg 0.5 1.5 2.3
Suitable for
PM240 Power Module
Type 6SL3224-0BE13-7UA0
6SL3224-0BE15-5UA0
6SL3224-0BE17-5UA0
6SL3224-0BE21-1UA0
6SL3224-0BE21-5UA0
6SL3224-0BE22-2AA0
6SL3224-0BE23-0AA0
6SL3224-0BE24-0AA0
6SL3224-0BE25-5AA0
6SL3224-0BE27-5AA0
6SL3224-0BE31-1AA0
Suitable for
PM250 Power Module
– – 6SL3225-0BE25-5AA0
6SL3225-0BE27-5AA0
6SL3225-0BE31-1AA0
Frame size FSA FSB FSC
© Siemens AG 2009
