SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Line-side power components
Line filters
4/75
Siemens D 11.1 · 2009
4
■ Integration
Frame size FSA of the PM240 Power Module is available only
without integrated class A line filter. A base filter is therefore
available so that class A can be achieved. A class B base filter
is also available so that class B can be achieved.
Frame sizes FSB and FSC of the PM240 Power Module are avail-
able both with and without integrated class A line filter. For com-
pliance with class B, PM240 Power Modules with integrated
class A line filter must be fitted additionally with a base filter to
class B.
An external class A line filter is available for frame size FSGX of
the PM240 Power Module.
Frame sizes FSC of the PM250 Power Module are available only
with integrated class A line filter. For compliance with class B,
PM250 Power Modules must be fitted additionally with a class B
base filter.
No additional Class B line filters are available for the PM260
Power Module.
Line filters which are optionally available depending on the Power Module used
U = Base component
S = Lateral mounting
I = Integrated
– = Not possible
F = Power Modules available with and without integrated class A filter
Frame size
FSA FSB FSC FSD FSE FSF FSGX
PM240 Power Module with integrated brake chopper without inte-
grated brake
chopper
Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓
Line-side power components
Line filter, class A U F F F F F/S
1)
S
1)
Line filter, class B U U U – – – –
PM250 Power Module with line-commutated energy recovery
Available frame sizes – – ✓ ✓ ✓ ✓ –
Line-side power components
Line filter, class A – – I F F F –
Line filter, class B – – U – – – –
PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter
Available frame sizes – – – ✓ – ✓ –
Line-side power components
Line filter, class A – – – F – F –
Line filter, class B – – – – – – –
1)
PM240 FSF Power Modules, from 110 kW (150 hp) and higher and FSGX
are available only without an integrated class A filter. An optional class A
line filter for side mounting is available instead.
