SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Line-side power components
Line reactors
4/78
Siemens D 11.1 · 2009
4
■
Selection and ordering data
■
Integration
The line reactors for PM240 Power Modules, frame sizes FSA to
FSE, are designed as base components. The line reactor is
attached to the mounting surface and the Power Module is
mounted directly on the line reactor in a space-saving fashion.
The cables to the Power Module are already connected at the
line reactor.
The line reactor is connected to the line supply through terminals.
Line reactors which are optionally available depending on the Power Module used
U = Base component
S = Lateral mounting
– = Not possible
Rated power SINAMICS G120 PM240 Power Module Line reactor
kW hp Type 6SL3224-... Frame size Order No.
380 … 480 V 3 AC
0.37 0.50 0BE13-7UA0 FSA 6SE6400-3CC00-2AD3
0.55 0.75 0BE15-5UA0 FSA
0.75 1.0 0BE17-5UA0 FSA
6SE6400-3CC00-4AD3
1.1 1.5 0BE21-1UA0 FSA
1.5 2 0BE21-5UA0 FSA 6SE6400-3CC00-6AD3
2.2 3 0BE22-2 . A0 FSB 6SL3203-0CD21-0AA0
3.0 4 0BE23-0 . A0 FSB
4.0 5 0BE24-0 . A0 FSB 6SL3203-0CD21-4AA0
7.5 10 0BE25-5 . A0 FSC 6SL3203-0CD22-2AA0
11.0 15 0BE27-5 . A0 FSC
15.0 20 0BE31-1 . A0 FSC 6SL3203-0CD23-5AA0
18.5 25 0BE31-5 . A0 FSD 6SL3203-0CJ24-5AA0
22 30 0BE31-8 . A0 FSD
30 40 0BE32-2 . A0 FSD 6SL3203-0CD25-3AA0
37 50 0BE33-0 . A0 FSE 6SL3203-0CJ28-6AA0
45 60 0BE33-7 . A0 FSE
55 75 0BE34-5 . A0 FSF 6SE6400-3CC11-2FD0
75 100 0BE35-5 . A0 FSF
90 125 0BE37-5 . A0 FSF 6SE6400-3CC11-7FD0
110 150 0BE38-8UA0 FSF 6SL3000-0CE32-3AA0
132 200 0BE41-1UA0 FSF 6SL3000-0CE32-8AA0
160 250 0XE41-3UA0 FSGX 6SL3000-0CE33-3AA0
200 300 0XE41-6UA0 FSGX 6SL3000-0CE35-1AA0
250 400 0XE42-0UA0 FSGX
new
new
Frame size
FSA FSB FSC FSD FSE FSF FSGX
PM240 Power Module with integrated brake chopper without inte-
grated brake
chopper
Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓
Line-side power components
Line reactor U U U U U S S
PM250 Power Module with line-commutated energy recovery
Available frame sizes – – ✓ ✓ ✓ ✓ –
Line-side power components
Line reactor
1)
– – –
1)
–
1)
–
1)
–
1)
–
PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter
Available frame sizes – – – ✓ – ✓ –
Line-side power components
Line reactor
1)
– – – –
1)
– –
1)
–
1
