SINAMICS G120 - Page 79

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Line-side power components
Line reactors
4/79
Siemens D 11.1 · 2009
4
■ Technical specifications
Line supply voltage
380…480V3AC
Line reactor
6SE6400-3CC00-2AD3 6SE6400-3CC00-4AD3 6SE6400-3CC00-6AD3 6SL3203-0CD21-0AA0
Rated current A 1.9 3.5 4.8 9
Power loss
at 50/60 Hz, approx.
W 6/7 12.5/15 7.5/9 9/11
Line supply connection
U1, V1, W1
Screw terminals Screw terminals Screw terminals Screw terminals
• Conductor cross-section mm
2
6 6 6 6
Load connection Cable Cable Cable Cable
• Conductor cross-section 4 × AWG16
(1.5 mm
2
)
4 × AWG16
(1.5 mm
2
)
4 × AWG16
(1.5 mm
2
)
4 × AWG16
(1.5 mm
2
)
• Length, approx. m 0.38 0.38 0.38 0.46
PE connection On housing with
M5 screw studs
On housing with
M5 screw studs
On housing with
M5 screw studs
On housing with
M5 screw studs
Degree of protection IP20 IP20 IP20 IP20
Dimensions
• Width mm 75.5 75.5 75.5 153
•Height mm 200 200 200 290
•Depth mm 50 50 50 50
Possible as base component yes yes yes yes
Weight, approx. kg 0.6 0.8 0.6 3.4
Suitable for
PM240 Power Module
Type 6SL3224-0BE13-7UA0
6SL3224-0BE15-5UA0
6SL3224-0BE17-5UA0
6SL3224-0BE21-1UA0
6SL3224-0BE21-5UA0 6SL3224-0BE22-2 . A0
6SL3224-0BE23-0 . A0
Frame size FSA FSA FSA FSB
Line supply voltage
380…480V3AC
Line reactor
6SL3203-0CD21-4AA0 6SL3203-0CD22-2AA0 6SL3203-0CD23-5AA0 6SL3203-0CJ24-5AA0
Rated current A 11.6 25 31.3 47
Power loss
at 50/60 Hz, approx.
W 27/32 98/118 37/44 90/115
Line supply connection
U1, V1, W1
Screw terminals Screw terminals Screw terminals Screw terminals
• Conductor cross-section
mm
2
6 6 16 16
Load connection
Cable Cable Cable Cable
• Conductor cross-section
4 × AWG16
(1.5 mm
2
)
4 × AWG10
(2.5 mm
2
)
4 × AWG10
(2.5 mm
2
)
4 × 16 mm
2
• Length, approx. m 0.46 0.49 0.49 0.7
PE connection On housing with
M5 screw studs
On housing with
M5 screw studs
On housing with
M5 screw studs
On housing with
M8 screw
Degree of protection IP20 IP20 IP20 IP20
Dimensions
• Width mm 153 189 189 275
•Height mm 290 371 371 455
•Depth mm 50 50 50 84
Possible as base component yes yes yes yes
Weight, approx. kg 3.4 5.2 5.9 13
Suitable for
PM240 Power Module
Type 6SL3224-0BE24-0 . A0 6SL3224-0BE25-5 . A0
6SL3224-0BE27-5 . A0
6SL3224-0BE31-1 . A0 6SL3224-0BE31-5 . A0
6SL3224-0BE31-8 . A0
Frame size FSB FSC FSC FSD
© Siemens AG 2009
