SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Line-side power components
Line reactors
4/80
Siemens D 11.1 · 2009
4
■
Technical specifications
Line supply voltage
380 … 480 V 3 AC
Line reactor
6SL3203-
0CD25-3AA0
6SL3203-
0CJ28-6AA0
6SE6400-
3CC11-2FD0
6SE6400-
3CC11-7FD0
6SL3000-
0CE32-3AA0
6SL3000-
0CE32-8AA0
Rated current A 63 94 151 186 224 278
Power loss
at 50/60 Hz, approx.
W 90/115 170/215 280/360 280/360 240/270 210/250
Line supply connection
U1, V1, W1
Screw terminals Screw terminals Flat connector
for M10 cable
lug
Flat connector
for M10 cable
lug
Flat connector
for M10 screw
Flat connector
for M10 screw
• Conductor cross-section mm
2
16 50 – – – –
Load connection Cable Cable Flat connector
for M10 cable
lug
Flat connector
for M10 cable
lug
Flat connector
for M10 screw
Flat connector
for M10 screw
• Conductor cross-section mm
2
4 × 16 4 × 35 – – – –
• Length, approx. m 0.7 0.7 – – – –
PE connection On housing with
M8 screw
On housing with
M8 screw
On housing with
M8 screw stud
On housing with
M8 screw stud
M6 screw M6 screw
Degree of protection IP20 IP20 IP00 IP00 IP00 IP00
Dimensions
• Width mm 275 275 240 240 270 270
•Height mm 455 577 228 228 248 248
•Depth mm 84 94 141 141 200 200
Possible as base component yes yes no no no no
Weight, approx. kg 13 19 25 25 24 24
Suitable for
PM240 Power Module
Type 6SL3224-
0BE32-2 . A0
6SL3224-
0BE33-0 . A0
6SL3224-
0BE33-7 . A0
6SL3224-
0BE34-5 . A0
6SL3224-
0BE35-5 . A0
6SL3224-
0BE37-5 . A0
6SL3224-
0BE38-8UA0
6SL3224-
0BE41-1UA0
Frame size FSD FSE FSF FSF FSF FSF
Line supply voltage
380…480V3AC
Line reactor
6SL3000-0CE33-3AA0 6SL3000-0CE33-5AA0
Rated current
A 331 508
Power loss
at 50/60 Hz, approx.
W 0.267 0.365
Line supply connection
U1, V1, W1
1 × hole for M10 1 × hole for M12
• Conductor cross-section mm
2
provided for busbar connection provided for busbar connection
Load connection
• Conductor cross-section mm
2
provided for busbar connection provided for busbar connection
PE connection M6 screw M6 screw
Degree of protection IP00 IP00
Dimensions
• Width mm 270 300
•Height mm 248 269
•Depth mm 200 212
Possible as base component no no
Weight, approx. kg 27.8 38.0
Suitable for
PM240 Power Module
Type 6SL3224-0XE41-3UA0 6SL3224-0XE41-6UA0
6SL3224-0XE42-0UA0
Frame size
FSGX FSGX
