■ Overview
The following table lists recommendations for additional line-
side components, such as fuses and circuit breakers (line-side
components dimensioned in accordance with IEC standards).
The specified circuit breakers are UL-certified.
3NA3 fuses are recommended for European countries. The
3NE1 fuses are UL-compliant (corresponds to RU). The values
in the table take into account the overload capability of the in-
verter.
Additional information about the listed fuses and circuit breakers
can be found in Catalogs LV 1 and LV 1 T.
■ Selection and ordering data
Rated power SINAMICS G120
PM240 Power Modules
Fuse Circuit breaker
Type 3NA3 Type 3NE1 (RU)
kW hp Type 6SL3224-... Frame size Order No. Order No. Order No.
380 … 480 V 3 AC
0.37 0.50 0BE13-7UA0 FSA 3NA3803 UL-listed fuses such as
the Class NON fuse
series from Bussmann
are required for North
America.
3RV1021-1CA10
0.55 0.75 0BE15-5UA0 FSA 3RV1021-1DA10
0.75 1.0 0BE17-5UA0 FSA 3RV1021-1FA10
1.1 1.5 0BE21-1UA0 FSA 3RV1021-1GA10
1.5 2 0BE21-5UA0 FSA 3RV1021-1JA10
2.2 3 0BE22-2 . A0 FSB 3NA3805 3RV1021-1KA10
3.0 4 0BE23-0 . A0 FSB 3RV1021-4AA10
4.0 5 0BE24-0 . A0 FSB 3NA3807 3RV1021-4BA10
7.5 10 0BE25-5 . A0 FSC 3RV1031-4EA10
11.0 15 0BE27-5 . A0 FSC 3NA3812 3RV1031-4FA10
15.0 20 0BE31-1 . A0 FSC 3NA3814 3RV1031-4HA10
18.5 25 0BE31-5 . A0 FSD 3NA3820 3NE1817-0 3RV1042-4KA10
22 30 0BE31-8 . A0 FSD 3NA3822 3NE1818-0
30 40 0BE32-2 . A0 FSD 3NA3824 3NE1820-0 3RV1042-4MA10
37 50 0BE33-0 . A0 FSE 3NA3830 3NE1021-0 3VL1712-.DD33-....
45 60 0BE33-7 . A0 FSE 3NA3832 3NE1022-0 3VL1716-.DD33-....
55 75 0BE34-5 . A0 FSF 3NA3836 3NE1224-0 3VL3720-.DC36-....
75 100 0BE35-5 . A0 FSF 3NA3140 3NE1225-0 3VL3725-.DC36-....
90 125 0BE37-5 . A0 FSF 3NA3144 3NE1227-0 3VL4731-.DC36-....
110 150 0BE38-8UA0 FSF –
132 200 0BE41-1UA0 FSF – 3NE1230-0
160 250 0XE41-3UA0 FSGX 3NA3254 3NE1333-2 3VL4740-.DC36-....
200 300 0BE41-6UA0 FSGX
3NA3260 3VL5750-.DC36-....
250 400 0BE42-0UA0 FSGX
3NA3372 3NE1436-2
