SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Line-side power components
Recommended line components
4/82
Siemens D 11.1 · 2009
4
■ Selection and ordering data
Rated power SINAMICS G120 PM250 Power
Modules
Fuse Circuit breaker
Type 3NA3 Type 3NE1 (RU)
kW hp Type 6SL3225-... Frame size Order No. Order No. Order No.
380 … 480 V 3 AC
7.5 10 0BE25-5AA0 FSC 3NA3807 UL-listed fuses such as the
Class NON fuse series from
Bussmann are required for
North America.
3RV1031-4EA10
11.0 15 0BE27-5AA0 FSC 3NA3812 3RV1031-4FA10
15.0 20 0BE31-1AA0 FSC 3NA3814 3RV1031-4HA10
18.5 25 0BE31-5 . A0 FSD 3NA3820 3NE1817-0 3RV1042-4KA10
22 30 0BE31-8 . A0 FSD 3NA3822 3NE1818-0
30 40 0BE32-2 . A0 FSD 3NA3824 3NE1820-0 3RV1042-4MA10
37 50 0BE33-0 . A0 FSE 3NA3830 3NE1021-0 3VL1712-.DD33-....
45 60 0BE33-7 . A0 FSE 3NA3832 3NE1022-0 3VL1716-.DD33-....
55 75 0BE34-5 . A0 FSF 3NA3836 3NE1224-0 3VL3720-.DC36-....
75 100 0BE35-5 . A0 FSF 3NA3140 3NE1225-0 3VL3725-.DC36-....
90 125 0BE37-5 . A0 FSF 3NA3144 3NE1227-0 3VL4731-.DC36-....
Rated power SINAMICS G120 PM260 Power
Modules
Fuse Circuit breaker
Type 3NA3 Type 3NE1 (RU)
kW hp Type 6SL3225-... Frame size Order No. Order No. Order No.
500 … 690 V 3 AC
11.0 15 0BH27-5 . A1 FSD 3NA3120-6 – 3RV1041-4FA10
15.0 20 0BH31-1 . A1 FSD
18.5 25 0BH31-5 . A1 FSD
30 40 0BH32-2 . A1 FSF 3NA3122-6 3RV1041-4JA10
37 50 0BH33-0 . A1 FSE 3RV1041-4KA10
55 75 0BH33-7 . A1 FSF 3NA3130-6 3RV1041-4MA10
