SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
SINAMICS G120 standard inverters
4/8
Siemens D 11.1 · 2009
4
■
Design
Maximum permissible cable lengths from the motor to the
inverter when using output reactors or sine-wave filters
depending on the voltage range and the Power Module being
used
The following load-side power components in the appropriate
frame sizes are optionally available for the Power Modules and
result in the following maximum cable lengths:
Maximum permissible motor cable lengths (shielded/unshielded) in m
Frame sizes
FSA FSB FSC FSD FSE FSF FSGX
PM240 Power Module with integrated brake chopper without inte-
grated brake
chopper
Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓
Without output reactor/sine-wave filter
50/100 50/100 50/100 50/100 100/100 150/150 300/450
With optional output reactor
• at 380 V (– 10 %) to 400 V 3 AC 150/225 150/225 150/225 200/300 200/300 200/300 300/450
• at 401 V to 480 V (+ 10 %) 3 AC 100/150 100/150 100/150 200/300 200/300 200/300 300/450
With optional sine-wave filter
• at 380 V (– 10 %) to 400 V 3 AC 200/300 200/300 200/300 200/300 200/300 200/300 300/450
• at 401 V to 480 V (+ 10 %) 3 AC 200/300 200/300 200/300 200/300 200/300 200/300 300/450
PM250 Power Module with line-commutated energy recovery
Available frame sizes – – ✓ ✓ ✓ ✓ –
Without output reactor/sine-wave filter – – 50/100 50/100 50/100 50/100 –
With optional output reactor
• at 380 V (– 10 %) to 400 V 3 AC – – 150/225 200/300 200/300 200/300 –
• at 401 V to 480 V (+ 10 %) 3 AC – – 100/150 200/300 200/300 200/300 –
With optional sine-wave filter
• at 380 V (– 10 %) to 400 V 3 AC – – 200/300 200/300 200/300 200/300 –
• at 401 V to 480 V (+ 10 %) 3 AC – – 200/300 200/300 200/300 200/300 –
PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter
Available frame sizes – – – ✓ – ✓ –
With integrated sine-wave filter
• at 500 V to 690 V 3 AC (± 10 %) – – – 200/300 – 200/300 –
