SINAMICS G120 - Page 90

SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Load-side power components
Output reactors
4/90
Siemens D 11.1 · 2009
4
■ Technical specifications
Line supply voltage
380…480V3AC
Output reactor (for a 4 kHz pulse frequency)
6SE6400-3TC00-4AD2
Rated current A 4 4 4 4 4
Power loss kW 0.005 0.005 0.005 0.005 0.005
Connection to the
Power Module
Cable Cable Cable Cable Cable
• Conductor cross-section 4 × AWG16
(1.5 mm
2
)
4 × AWG16
(1.5 mm
2
)
4 × AWG16
(1.5 mm
2
)
4 × AWG16
(1.5 mm
2
)
4 × AWG16
(1.5 mm
2
)
• Length, approx. m 0.3 0.3 0.3 0.3 0.3
Motor connection Screw terminals Screw terminals Screw terminals Screw terminals Screw terminals
• Conductor cross-section mm
2
6 6 6 6 6
PE connection M5 screw studs M5 screw studs M5 screw studs M5 screw studs M5 screw studs
Cable length, max.
between output reactor and
motor
• 380 V (– 10 %) ... 400 V 3 AC
- Shielded m 150 150 150 150 150
- Unshielded m 225 225 225 225 225
• 401 V... 480 V (+ 10 %) 3 AC
- Shielded m 100 100 100 100 100
- Unshielded m 150 150 150 150 150
Dimensions
• Width mm 75.5 75.5 75.5 75.5 75.5
•Height mm 200 200 200 200 200
•Depth mm 110 110 110 110 110
Possible as base
component
yes yes yes yes yes
Degree of protection IP00 IP00 IP00 IP00 IP00
Weight, approx. kg 2 2 2 2 2
Suitable for
PM240 Power Module
Type 6SL3224-
0BE13-7UA0
6SL3224-
0BE15-5UA0
6SL3224-
0BE17-5UA0
6SL3224-
0BE21-1UA0
6SL3224-
0BE21-5UA0
Rated power of the
Power Module
kW (hp) 0.37 (0.5) 0.55 (0.75) 0.75 (1.0) 1.1 (1.5) 1.5 (2.0)
Rated current I
rated
of the
Power Module
A 1.3 1.7 2.2 3.1 4.1
Frame size FSA FSA FSA FSA FSA
