SINAMICS G120

Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)

Load-side power components

Output reactors

4/89

Siemens D 11.1 · 2009

■

Integration

Output reactors which are optionally available depending on

the Power Module used

The following line-side power components, DC link components

and load-side power components are optionally available in the

appropriate frames sizes for the Power Modules:

U = Base component

S = Lateral mounting

– = Not possible

Frame size

FSA FSB FSC FSD FSE FSF FSGX

PM240 Power Module with integrated brake chopper without inte-

grated brake

chopper

Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓

Load-side power components

Output reactor U U U S S S S

PM250 Power Module with line-commutated energy recovery

Available frame sizes – – ✓ ✓ ✓ ✓ –

Load-side power components

Output reactor – – U S S S –

PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter

Available frame sizes – – – ✓ – ✓ –

Load-side power components

Output reactor

– – – – – – –

PM260 Power Modules do not require output reactors as they are already

equipped with sine-wave filters.
