SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Load-side power components
Output reactors
4/92
Siemens D 11.1 · 2009
4
■
Technical specifications
Line supply voltage
380…480V3AC
Output reactor (for a 4 kHz pulse frequency)
6SE6400-
3TC05-4DD0
6SE6400-
3TC03-8DD0
6SE6400-
3TC05-4DD0
6SE6400-
3TC08-0ED0
6SE6400-
3TC07-5ED0
Rated current A 68
1)
45
1)
68
1)
104
1)
90
1)
Power loss kW 0.2 0.2 0.2 0.17 0.27
Connection to the
Power Module
Flat connector for
M6 cable lug
Flat connector for
M6 cable lug
Flat connector for
M6 cable lug
Flat connector for
M6 cable lug
Flat connector for
M6 cable lug
Motor connection Flat connector for
M6 cable lug
Flat connector for
M6 cable lug
Flat connector for
M6 cable lug
Flat connector for
M6 cable lug
Flat connector for
M6 cable lug
PE connection M6 screw M6 screw M6 screw M6 screw M6 screw
Cable length, max.
between output reactor and
motor
• 380 V (– 10 %) ... 400 V 3 AC
- Shielded m 200 200 200 200 200
- Unshielded m 300 300 300 300 300
• 401 V ... 480 V (+ 10 %) 3 AC
- Shielded m 200 200 200 200 200
- Unshielded m 300 300 300 300 300
Dimensions
• Width mm 225 225 225 225 270
•Height mm 210 210 210 210 248
•Depth mm 150 179 150 150 209
Possible as base
component
no no no no no
Degree of protection IP00 IP00 IP00 IP00 IP00
Weight, approx. kg 10.7 16.1 10.7 10.4 24.9
Suitable for
PM240 Power Module
Type 6SL3224-
0BE31-5UA0
6SL3224-
0BE31-5AA0
6SL3224-
0BE31-8UA0
6SL3224-
0BE31-8AA0
6SL3224-
0BE32-2UA0
6SL3224-
0BE32-2AA0
6SL3224-
0BE33-0UA0
6SL3224-
0BE33-0AA0
6SL3224-
0BE33-7UA0
6SL3224-
0BE33-7AA0
Suitable for
PM250 Power Module
Type 6SL3225-
0BE31-5 . A0
6SL3225-
0BE31-8 . A0
6SL3225-
0BE32-2 . A0
6SL3225-
0BE33-0 . A0
6SL3225-
0BE33-7 . A0
Rated power of the
Power Module
kW (hp) 18.5 (25) 22 (30) 30 (40) 37 (50) 45 (60)
Rated current I
rated
of the
Power Module
A 38 45 60 75 90
Frame size
FSD FSD FSD FSE FSE
1)
On the rating plate of the reactor the current is displayed according to
High Overload HO, which is lower than the indicated value for the Light
Overload current of the Power Module.
