SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Load-side power components
Output reactors
4/93
Siemens D 11.1 · 2009
4
■
Technical specifications
Line supply voltage
380…480V3AC
Output reactor (for a 4 kHz pulse frequency)
6SE6400-
3TC14-5FD0
6SE6400-
3TC15-4FD0
6SE6400-
3TC14-5FD0
6SL3000-
2BE32-1AA0
6SL3000-
2BE32-6AA0
Rated current A 178
1)
178
1)
178
1)
210 260
Power loss kW 0.47 0.25 0.47 0.49 0.5
Connection to the
Power Module
Flat connector for
M8 cable lug
Flat connector for
M8 cable lug
Flat connector for
M8 cable lug
Flat connector for
M10 screw
Flat connector for
M10 screw
Motor connection Flat connector for
M8 cable lug
Flat connector for
M8 cable lug
Flat connector for
M8 cable lug
Flat connector for
M10 screw
Flat connector for
M10 screw
PE connection M8 screw M6 screw M8 screw M8 screw M8 screw
Cable length, max.
between output reactor and
motor
• 380 V (– 10 %) ... 400 V 3 AC
- Shielded m 200 200 200 200 200
- Unshielded m 300 300 300 300 300
• 401 V ... 480 V (+ 10 %) 3 AC
- Shielded m 200 200 200 200 200
- Unshielded m 300 300 300 300 300
Dimensions
• Width mm 350 270 350 300 300
•Height mm 321 248 321 285 315
•Depth mm 288 209 288 257 277
Possible as base
component
no no no no no
Degree of protection IP00 IP00 IP00 IP00 IP00
Weight, approx. kg 51.5 24 51.5 60 66
Suitable for
PM240 Power Module
Type 6SL3224-
0BE34-5UA0
6SL3224-
0BE34-5AA0
6SL3224-
0BE35-5UA0
6SL3224-
0BE35-5AA0
6SL3224-
0BE37-5UA0
6SL3224-
0BE37-5AA0
6SL3224-
0BE38-8UA0
6SL3224-
0BE41-1UA0
Suitable for
PM250 Power Module
Type 6SL3225-
0BE34-5 . A0
6SL3225-
0BE35-5 . A0
6SL3225-
0BE37-5 . A0
– –
Rated power of the
Power Module
kW (hp) 55 (75) 75 (100) 90 (125) 110 (150) 132 (200)
Rated current I
rated
of the
Power Module
A 110 145 178 205 250
Frame size
FSF FSF FSF FSF FSF
1)
On the rating plate of the reactor the current is displayed according to
High Overload HO, which is lower than the indicated value for the Light
Overload current of the Power Module.
