SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Load-side power components
Output reactors
4/94
Siemens D 11.1 · 2009
4
■ Technical specifications
Line supply voltage
380…480V3AC
Output reactor (for a 4 kHz pulse frequency)
6SL3000-2BE33-2AA0 6SL3000-2BE33-8AA0 6SL3000-2BE35-0AA0
Rated current A 310 380 490
Power loss kW 0.470 0.500 0.500
Connection to the
Power Module
1 × hole for M10 1 × hole for M10 1 × hole for M12
Motor connection 1 × hole for M10 1 × hole for M10 1 × hole for M12
PE connection M6 screw M6 screw M6 screw
Cable length, max.
between output reactor and
motor
• 380 V (– 10 %) ... 400 V 3 AC
- Shielded m 300 300 300
- Unshielded m 450 450 450
• 401 V ... 480 V (+ 10 %) 3 AC
- Shielded m 300 300 300
- Unshielded m 450 450 450
Dimensions
• Width mm 300 300 300
•Height mm 285 285 365
•Depth mm 257 277 277
Possible as base
component
no no no
Degree of protection IP00 IP00 IP00
Weight, approx. kg 66 73 100
Suitable for
PM240 Power Module
Type 6SL3224-0XE41-3UA0 6SL3224-0XE41-6UA0 6SL3224-0XE42-0UA0
Suitable for
PM250 Power Module
Type – – –
Rated power of the
Power Module
kW (hp) 160 (250) 200 (300) 250 (400)
Rated current I
rated
of the
Power Module
A 302 370 477
Frame size FSGX FSGX FSGX
