SINAMICS G120
Standard inverters 0.37 kW to 250 kW (0.5 hp to 400 hp)
Load-side power components
Sine-wave filters
4/96
Siemens D 11.1 · 2009
4
■
Integration
Sine-wave filters which are optionally available depending on the Power Module used
U = Base component
S = Lateral mounting
I = Integrated
– = Not possible
Frame size
FSA FSB FSC FSD FSE FSF FSGX
PM240 Power Module with integrated brake chopper without inte-
grated brake
chopper
Available frame sizes ✓ ✓ ✓ ✓ ✓ ✓ ✓
Load-side power components
Sine-wave filter U U U S S S S
PM250 Power Module with line-commutated energy recovery
Available frame sizes – – ✓ ✓ ✓ ✓ –
Load-side power components
Sine-wave filter – – U S S S –
PM260 Power Module with line-commutated energy recovery and integrated sine-wave filter
Available frame sizes – – – ✓ – ✓ –
Load-side power components
Sine-wave filter – – – I – I –
